EXCEPTIONAL PERFORMANCE & LOW OPERATING COSTS
Evo Advanced DHP-R series delivers pool heating with exceptional performance, low operating costs & a C.O.P. as high as 5.4.
Combine your Evo pool heat pump with a pool blanket &/or your solar PV for the ultimate energy
efficient pool heating!
CUTTING EDGE FULL COLOUR TOUCHSCREEN CONTROLLER
Featuring an easy to use,
intelligent full colour touch screen controller that allows you to maintain your pool temperature to within 0.1 degree while delivering optimum performance.
WI-FI Control
Control your Evo Advanced DHP-R heat pump anytime, anywhere with the smart
Wi-Fi controller app. Available for iOS and Android, the smart phone controller app offers you an
easy and convenient way to monitor and control your pool temperature.
HEATING & COOLING MODES
The Advanced DHP-R series is equipped to automatically heat or cool your pool water based on your set temperature - so you can be sure your pool is always at your desired temperature!
VERY QUIET OPERATION + DUAL SPEED FANS
Our low noise fan blades ensures minimal operating noise which is ideal for you and your neighbours! Plus, the dual speed fan allows you to run your heat pump during the night with even further reduced noise levels. The fan is able to operate on a lower RPM on a timer or ambient temperature basis. * Dual speed fans available on selected models - refer to website for most up to date models.
LOW AMBIENT AIR PERFORMANCE
The Evo Advanced DHP-R heat pump offers low running times because of its higher heat outputs when it counts.
304 STAINLESS STEEL CABINET
The 304 stainless steel cabinet will ensure long term corrosion
resistance.
DUAL DEFROST TECHNOLOGY
Our Thermotec Element Defrost technology and auto defrost system ensures your heat pump is defrosting less and heating more often, maximizing the
heating capacity in colder weather when its needed the most.
TITANIUM HEAT EXCHANGER
The titanium thread heat exchanger ensures maximum heat transfer with the ultimate corrosion resistance, improving the heat transfer efficiency by up to 30% compared to standard heat exchangers.
ELECTRONIC EXPANSION VALVE 2 TECHNOLOGY
Electronic Expansion Valve 2 Technology is the absolute latest and the best possible refrigeration control system available in the market today. This results in higher C.O.P. and improved efficiency of up to 20% compared to other
commercial heater brands.
LATEST CORROSION PROTECTION TECHNOLOGY
The bluetec hydrophilic coating on the condenser fins is the latest technology in corrosion protection allowing your heat pump to
maintain its high efficiency for many years to come.
Inexpensive to run
A fraction of the running cost of Gas pool heating
Swim in a heated pool all year
Unlike solar
heating which only effectively extends the
swimming season by a few months, an Aquatight
Heat Pump heats continuously even when it’s cool
and cloudy
Incredibly efficient
Japanese inverter technology
- massive 6.2 COP (Coefficient of Performance)
- 15-30% higher efficiency than competitive units
Top quality, maximum durability Titanium Heat
Exchanger
Installation is quick and easy
You could be
swimming in a warm pool in no time
Attractive, unobtrusive heating unit
Model Specifications:
IM13 – 13kW
IM15 – 15kW
Saturn Heat Pump Specifications:
• Power Supply: 230V / Single phase / 50Hz
• Water pipe in-out size (mm): 48.3
• Dimensions (mm) L x W x H: 872 x 349 x 654
• R410a Refrigerant
Model Specifications:
iXB09:
Advised Pool volume (L): 20,000 to 35,000*
Heating Capacity / COP:-
At 26°C air Temp / Water Temp to 26°C / 80% Humidity
- 8.0kW
- COP 10.4 – 5.6
At 15°C air Temp / Water Temp to 26°C / 70% Humidity
- 6.0kW
- COP 6.1 – 4.1
Rated Input Current at 15°C Air: 1.48 – 6.0
Sound pressure at 1m dB(A): 40.8 – 51.1
Weight: 46kg
iX09:
Advised Pool volume (L): 20,000 to 40,000*
Heating Capacity / COP:-
At 26°C air Temp / Water Temp to 26°C / 80% Humidity
- 9.2kW
- COP 11 – 5.7
At 15°C air Temp / Water Temp to 26°C / 70% Humidity
- 7.0kW
- COP 6.2 – 4.3
Rated Input Current at 15°C Air: 1.48 – 7.0
Sound pressure at 1m dB(A): 40.6 – 52.5
Weight: 47kg
iX12:
Advised Pool Volume (L): 30,000 to 55,000*
Heating Capacity / COP:-
At 26°C air Temp / Water Temp to 26°C / 80% Humidity
- 12.5kW
- COP 12.1 – 5.9
At 15°C air Temp / Water Temp to 26°C / 70% Humidity
- 9.0kW
- COP 6.1 – 4.2
Rated Input Current at 15°C Air: 1.57 – 8.7
Sound pressure at 1m dB(A): 42.9 – 53
Weight: 49kg
Specifications correct at the time of publishing and are subject to change without notice.
*The Advised Pool Volume indicated is a guide only and applies under following conditions: Swimming pool is well covered; system runs at least 15 hours per day;
If these conditions are not met, please kindly ask your nearest Southside Pool store for advice.
EXCEPTIONAL PERFORMANCE & LOW OPERATING COSTS
Evo Fusion-i series
delivers pool heating with exceptional performance, low operating costs & a C.O.P. as high as 12.57 .
Combine your Evo Fusion-i pool heat pump with a pool blanket &/or your
solar PV for the ultimate energy efficient pool heating!
LATEST STEPLESS DC FULL INVERTER TECHNOLOGY
Incorporating the latest full
inverter technology - including DC stepless compressors, fans, and PC boards; the Fusion-i
range will automatically adjust it’s power and electricity consumption based on the exact
requirements of your pool. This ensures your pool reaches the desired temperature
faster, and is maintained more efficiently - SAVING YOU ON YOUR HOUSEHOLD ENERGY BILL.
TOUCHSCREEN CONTROLLER
Designed with an intelligent LCD touch screen controller, you can easily increase or decrease water temperatures and switch between heating and cooling modes.
HEATING & COOLING MODES
The Fusion-i series is equipped to automatically heat or cool your pool water based on your set temperature - so you can be sure your pool is
always at your desired temperature!
VERY QUIET OPERATION
Our low noise fan blades ensures minimal operating noise which is ideal for you and your neighbours!
AUTOMATIC DEFROST
Designed with a four-way valve reverse defrost method, the Fusion-i series provides automatic defrosting and allows the heat pump to work
efficiently in ambient air temperatures as low as -7°C.
TITANIUM HEAT EXCHANGER
The titanium thread heat exchanger ensures maximum heat transfer with the ultimate corrosion resistance, improving the heat transfer efficiency by up to 30% compared to standard heat exchangers.
ELECTRONIC EXPANSION VALVE 2 TECHNOLOGY
Electronic Expansion Valve 2 Technology is the absolute latest and the best possible refrigeration control system available in the market today. This results in higher C.O.P. and improved efficiency of up
to 20% compared to other commercial heater brands.
LATEST CORROSION PROTECTION TECHNOLOGY
The bluetec hydrophilic coating on the condenser fins is the latest technology in corrosion protection allowing your heat pump to maintain its high efficiency for many years to come.
